CJ6250SA Universal horizontal Lathe
Feature:
l The guide surface hardened by superfrequency and precision ground
l All gears hardened and precision ground
l Be good at rigidity and accuracy
l Whole foot stand
l
CJ6250SA Universal horizontal Lathe
|
Model NO.
|
CJ6240SA
|
CJ6250SA
|
|
Swing over bed
|
Φ400mm
|
Φ500mm
|
|
Swing over carriage
|
Φ220mm
|
Φ300mm
|
|
Max. Swing in gap
|
Φ630mm
|
Φ710mm
|
|
Max. Length of workpiece
|
1000/1500/2000/3000mm
|
|
Effective gap length
|
230mm
|
|
Bed width
|
390mm
|
|
Spindle bore
|
Φ82( D8)
|
|
Spindle taper of bore
|
No.6(Morse) 1:20, Φ90
|
|
Spindle number speed
|
24 steps
|
|
Spindle range of speed
|
9-1600rpm
|
|
Threads metric pitches
|
0.5-224mm/24
|
|
Threads imperial pitches
|
72~1/8T.P.I/48 kinds
|
|
Thread diametral pitches
|
56~1/4 D.P/45 kinds
|
|
Threads module pitches
|
0.5-112mm/42 kinds
|
|
Range of feeds longitudinal
|
0.028-6.43mm
|
|
Range of feeds cross
|
0.012mm-2.73mm
|
|
External diameter of the tailstock
quill
|
Φ75mm
|
|
Max. Traverse of the tailstock quill
|
130
|
|
Quill taper
|
NO. 5 (morse)
|
|
Max. Travel of tailstock sleeve
|
150mm
|
|
Max. Travel of compound rest
|
140mm
|
|
Max. Cross slide travel
|
329mm
|
|
Max. Size of tool shank(WxH)
|
25x25mm
|
|
Power of main motor
|
7.5kW
|
|
Over all size(LxWxH)
|
2382x975x1270mm
|
|
Net weight:
|
2900kg
|
